產品介紹：
|
類型 |
種類
|
25°C時額定功率(W)
|
阻值范圍(Ω)
|
|||
|
民用
|
軍用
|
阻值公差
(±%) |
阻值范圍
(Ω) |
溫度系數
(±PPM/°C) |
||
|
AHS-5
|
RE60G
|
5
|
5
|
0.1, 0.25, 0.5
|
10~1K
|
25
|
|
0.5, 1
|
1.0~3.32K
|
25, 50
|
||||
|
5, 10
|
0.1~3.32K
|
100, 250
|
||||
|
10
|
0.01~3.32K
|
100, 250
|
||||
|
AHS-5N
|
RE60N
|
5
|
5
|
1, 5
|
10~200
|
25, 50
|
|
5
|
1.0~860
|
100
|
||||
|
5, 10
|
0.1~860
|
100, 250
|
||||
|
10
|
0.01~1K
|
100, 250
|
||||
|
AHS-10
|
RE65G
|
10
|
10
|
0.1, 0.25, 0.5
|
10~1.2K
|
25, 50
|
|
0.5, 1
|
1.0-2.7K
|
50, 100
|
||||
|
5, 10
|
0.1~2.7K
|
100, 250
|
||||
|
10
|
0.01~5.62K
|
100, 250
|
||||
|
AHS-10N
|
RE65N
|
10
|
10
|
1, 5
|
10~860
|
25, 50
|
|
5
|
1.0~1.2K
|
100
|
||||
|
5, 10
|
0.1~1.2K
|
100, 250
|
||||
|
10
|
0.01~1.5K
|
100, 250
|
||||
|
AHS-25
|
RE70G
|
25
|
20
|
0.1, 0.25, 0.5
|
10~2.7K
|
25, 50
|
|
0.5, 1
|
1.0~3.9K
|
50, 100
|
||||
|
5, 10
|
0.1~3.9K
|
100, 250
|
||||
|
10
|
0.01~12.1K
|
100, 250
|
||||
|
AHS-25N
|
RE70N
|
25
|
20
|
1, 5
|
10~1.2K
|
25, 50
|
|
5
|
1.0~2.7K
|
100
|
||||
|
5, 10
|
0.1~2.7K
|
100, 250
|
||||
|
10
|
0.01~6.04K
|
100, 250
|
||||
|
AHS-50
|
RE75G
|
50
|
30
|
0.1, 0.25, 0.5
|
10~3.9K
|
25, 50
|
|
0.5, 1
|
1.0~5.6K
|
50, 100
|
||||
|
5, 10
|
0.1~5.6K
|
100, 250
|
||||
|
10
|
0. 01~39.2K
|
100, 250
|
||||
|
AHS-50N
|
RE75N
|
50
|
30
|
1, 5
|
10~2.7K
|
25, 50
|
|
5
|
1.0~3.9K
|
100
|
||||
|
5, 10
|
0.1~3.9K
|
100, 250
|
||||
|
10
|
0.01~19.6K
|
100, 250
|
||||
|
AHS-100
|
RE77G
|
100
|
75
|
0.1, 0.25, 0.5
|
10~5.6K
|
25, 50
|
|
0.5, 1
|
1.0~8.2K
|
50, 100
|
||||
|
5, 10
|
0.1~12K
|
100, 250
|
||||
|
10
|
0.01~29.4K
|
100, 250
|
||||
|
AHS-100N
|
RE77N
|
100
|
75
|
1,5
|
10~3.9K
|
25, 50
|
|
5
|
1.0~5.6K
|
100
|
||||
|
5, 10
|
0.1~5.6K
|
100, 250
|
||||
|
10
|
0.01~14.7K
|
100, 250
|
||||
|
AHS-250
|
RE80G
|
250
|
120
|
0.1, 0.25, 0.5
|
10~12K
|
25, 50
|
|
0.5, 1
|
1.0~27K
|
50, 100
|
||||
|
5, 10
|
0.1~27K
|
100, 250
|
||||
|
10
|
0.01~35.7K
|
100, 250
|
||||
|
AHS-250N
|
RE80N
|
250
|
120
|
1, 5
|
10~5.6K
|
25, 50
|
|
5
|
1.0~8.2K
|
100
|
||||
|
5, 10
|
0.1~8.2K
|
100, 250
|
||||
|
10
|
0.01~17.4K
|
100, 250
|
||||
|
注意: 產品尺寸可能變更，請以實際產品尺寸或本公司最新規格書為準. |
|
AHC 標 準 規 格 |
|
類型 |
25°C時額定功率(W)
|
阻值范圍 (Ω)
|
||
|
阻值公差
(±%) |
阻值范圍
(Ω) |
溫度系數
(±PPM/°C) |
||
|
AHC-5
|
5
|
0.1, 0.25, 0.5
|
10~1K
|
25
|
|
0.5, 1
|
1.0~3.32K
|
25, 50
|
||
|
5, 10
|
0.1~3.32K
|
100, 250
|
||
|
10
|
0.01~3.32K
|
100, 250
|
||
|
AHC-5N
|
5
|
1, 5
|
10~200
|
25, 50
|
|
5
|
1.0~860
|
100
|
||
|
5, 10
|
0.1~860
|
100, 250
|
||
|
10
|
0.01~1K
|
100, 250
|
||
|
AHC-10
|
10
|
0.1, 0.25, 0.5
|
10~1.2K
|
25, 50
|
|
0.5, 1
|
1.0-2.7K
|
50, 100
|
||
|
5, 10
|
0.1~2.7K
|
100, 250
|
||
|
10
|
0.01~5.62K
|
100, 250
|
||
|
AHC-10N
|
10
|
1, 5
|
10~860
|
25, 50
|
|
5
|
1.0~1.2K
|
100
|
||
|
5, 10
|
0.1~1.2K
|
100, 250
|
||
|
10
|
0.01~1.5K
|
100, 250
|
||
|
AHC-25
|
25
|
0.1, 0.25, 0.5
|
10~2.7K
|
25, 50
|
|
0.5, 1
|
1.0~3.9K
|
50, 100
|
||
|
5, 10
|
0.1~3.9K
|
100, 250
|
||
|
10
|
0.01~12.1K
|
100, 250
|
||
|
AHC-25N
|
25
|
1, 5
|
10~1.2K
|
25, 50
|
|
5
|
1.0~2.7K
|
100
|
||
|
5,10
|
0.1~2.7K
|
100, 250
|
||
|
10
|
0.01~6.04K
|
100, 250
|
||
|
AHC-50
|
50
|
0.1, 0.25, 0.5
|
10~3.9K
|
25, 50
|
|
0.5, 1
|
1.0~5.6K
|
50, 100
|
||
|
5, 10
|
0.1~5.6K
|
100, 250
|
||
|
10
|
0. 01~39.2K
|
100, 250
|
||
|
AHC-50N
|
50
|
1, 5
|
10~2.7K
|
25, 50
|
|
5
|
1.0~3.9K
|
100
|
||
|
5, 10
|
0.1~3.9K
|
100, 250
|
||
|
10
|
0.01~19.6K
|
100, 250
|
||
|
AHC-100
|
100
|
0.1, 0.25, 0.5
|
10~5.6K
|
25, 50
|
|
0.5, 1
|
1.0~8.2K
|
50, 100
|
||
|
5, 10
|
0.1~12K
|
100, 250
|
||
|
10
|
0.01~29.4K
|
100, 250
|
||
|
AHC-100N
|
100
|
1, 5
|
10~3.9K
|
25, 50
|
|
5
|
1.0~5.6K
|
100
|
||
|
5, 10
|
0.1~5.6K
|
100, 250
|
||
|
10
|
0.01~14.7K
|
100, 250
|
||
|
AHC-250
|
250
|
0.1, 0.25, 0.5
|
10~12K
|
25, 50
|
|
0.5, 1
|
1.0~27K
|
50, 100
|
||
|
5, 10
|
0.1~27K
|
100, 250
|
||
|
10
|
0.01~35.7K
|
100, 250
|
||
|
AHC-250N
|
250
|
1, 5
|
10~5.6K
|
25, 50
|
|
5
|
1.0~8.2K
|
100
|
||
|
5, 10
|
0.1~8.2K
|
100, 250
|
||
|
10
|
0.01~17.4K
|
100, 250
|
||
|
表面溫度與功率負載曲線圖(散熱板) |
|
 AH-5W/10W: Heatsink Required : 0.040 [1.0] Alum.Plate, 129 in2[832 cm2] or equiv.AH-25W: Heatsink Required : 0.040 [1.0] Alum.Plate, 167 in2[1077 cm2] or equiv. AH-50W: Heatsink Required : 0.059 [1.5] Alum.Plate, 291 in2[1877 cm2] or equiv. AH-100W: Heatsink Required : 0.125 [3.2] Alum.Plate, 294 in2[1896 cm2] or equiv. AH-250W: Heatsink Required : 0.125 [3.2] Alum.Plate, 895 in2[5780 cm2] or equiv. |
|
降功耗曲線圖 |
|
 為分解機箱面積適應高溫度環境產生功率衰減曲線.
曲率: A=5 & 10W,未用.B=25W,未用.C=50,100 & 250W,未用. |
|
溫升曲線圖 |
|
 REDUCED HEAT SINK DERATING:
Derating is also required when recommended heat sink area is reduced. A = AH-5 and AH-10 size resistor. B = AH-25 size resistor C = AH-50, AH-100 and AH-250 size resistor. |
|
性 能 |
|
參數 |
測試條件
|
規格
|
|
短時間過載
|
5 × 額定功率-5sec.
|
Δ R±(2%+0.05Ω)Max.
|
|
負載壽命
|
額定負載 (底盤安裝)
25°C (1.5 Hour on 0.5 Hour OFF) 重復 1000 小時 |
Δ R±(5%+0.05Ω)Max.
|
|
溫度系數阻值
|
溫度 40°C 濕度 95% DC 100V 500Hr
|
Δ R±(5%+0.05Ω)Max.
|
|
絕緣耐壓
|
AHS-5 AHS-10 AHS-25 1000V
AHS-50 2000V AHS-100 AHS-250 3000V |
Δ R±(0.5%+0.05Ω)Max.
|
|
AHC-5 AHC-10 AHC-25 1000V
AHC-50 1500V AHC-100 AHC-250 2500V |
||
|
絕緣阻抗
|
在同樣的介質耐壓測試條件下， 加載500V和絕緣性阻值測試
|
1000MΩMin.
|
|
引出端強度
|
(1)扭轉測試 (30 sec Min)
AH-5 1kg， AH-10 2.3kg， AH-25， AH-50 4.5kg (2)扭轉測試(5~15sec) AH-100 27kg-cm， AH-250 36kg-cm |
Δ R±(0.2%+0.05Ω)Max.
|
|
振動
|
10c/s~50c/s~10c/s(1Min)-2小時
平行和正確的角度 |
Δ R±(0.2%+0.05Ω)Max.
|
|
如何訂購 |
|
AH |
S
|
10/10N
|
20Ω
|
D
|
|||||||||||||||||||||||||||||||||||||||||||||||||||
 |
 |
 |
 |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||
